I think I found a minor issue with the mode button. When i fitted it into the gameboy case, the button was not long enough to push in. If I need to adjust the volume or something its not going to work well. So basily I soldered it out for a longer one I had.
https://i.imgur.com/f7rWi3M.jpg
Stock button on top, replacement on the side
https://i.imgur.com/4QoVhWl.jpg
https://i.imgur.com/w0cLQKE.jpg
New button in place
Besides not having a battery I am pretty much good to go, but I do think for future versions having a longer tact switch for the mode button would make things lot easier to use.
[SOLVED] CSO - The mode button is a little short
Re: The mode button is a little short
I saw last night that it was a known issue. I can't find it on the wiki now, Kite said it should be fixed for the next board. I ordered 6x6x7 to replace mine with, what length is the one you're using?
Re: The mode button is a little short
6 x 6 x 9mm Tactile Tact Push Button Switch 4 Pin DIP
Brand Name Amico
Material Plastic,Metal,ElectricParts
Model Number US-SA-AJD-07924
Part Number a12011500ux0294
UNSPSC Code 39122216
https://www.amazon.com/gp/product/B008D ... UTF8&psc=1
Brand Name Amico
Material Plastic,Metal,ElectricParts
Model Number US-SA-AJD-07924
Part Number a12011500ux0294
UNSPSC Code 39122216
https://www.amazon.com/gp/product/B008D ... UTF8&psc=1
- YaYa
- Posts: 1719
- Joined: Mon Jun 26, 2017 12:42 pm
- Location: brittany - France
- Has thanked: 871 times
- Been thanked: 689 times
- Contact:
Re: The mode button is a little short
I think 6x6x6 should be ok, isn’t it ?
Because 9mm is protruding very much lol
Because 9mm is protruding very much lol
- YaYa
- Posts: 1719
- Joined: Mon Jun 26, 2017 12:42 pm
- Location: brittany - France
- Has thanked: 871 times
- Been thanked: 689 times
- Contact:
Re: The mode button is a little short
You can still dremel it to shorten. That’s what i do to all the tactiles and it allows me to curve the sides of the top so that it does not hurts my finger when i press them.
Zoom in to see the rounded button
- kite
- Posts: 972
- Joined: Thu May 12, 2016 4:30 am
- Location: UK
- Has thanked: 246 times
- Been thanked: 361 times
- Contact:
Re: [SOLVED] CSO - The mode button is a little short
6x6x6 is what I specified originally to be put on the boards but they put something like 6x6x4 or something. I'm going to make sure they put longer ones on for the next order!
Stock clearance - CLOSED: viewtopic.php?f=38&t=12064
Kite's Mailing List: https://goo.gl/forms/e97uUvPOfUxPWdz82
Kite's FAQ: https://kiteretro.com/faq/
Kite's Mailing List: https://goo.gl/forms/e97uUvPOfUxPWdz82
Kite's FAQ: https://kiteretro.com/faq/
